BAUMER MIT3-F22.B18 MIT Pressure Gauge, 63 mm, 0 ... 2.5 bar
- Brand
- BAUMER
- Model
- MIT3-F22.B18
- GEARWELL SKU
- GWP-000020674
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy
- Class 2.5 (EN 837-1)
- Nominal size
- 63 mm
- Product line
- Bourdon pressure gauges (Baumer group)
- Case material
- Stainless steel
- Measuring range
- 0 ... 2.5 bar
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | BAUMER MIT3-F22.B18 MIT Pressure Gauge, 63 mm, 0 ... 2.5 bar |
|---|---|
| Brand | BAUMER |
| Model | MIT3-F22.B18 |
| Category | Pressure, Flow & Temperature |
| Accuracy | Class 2.5 (EN 837-1) |
| Nominal size | 63 mm |
| Product line | Bourdon pressure gauges (Baumer group) |
| Case material | Stainless steel |
| Measuring range | 0 ... 2.5 bar |
| Sensing element | Cupreous metal Bourdon tube |
| Type designation | MIT3-F22.B18 |
| Type of mounting | Back connection (F) |
| Code positions "22" | as collected (connection/filling digits); verify on order |
| Process connection | G 1/4 |
| Degree of protection | IP54 (IP65 for 100 mm dia.) |
| Operating temperature | -10 ... +70 °C |
