PANASONIC FM-252-4-P FM-200 Digital Flow Sensor 500 mL/min PNP
- Brand
- PANASONIC
- Model
- FM-252-4-P
- GEARWELL SKU
- GWP-000026476
- Category
- Pressure, Flow & Temperature
Key specifications
- Output
- PNP open-collector (comparative outputs 1/2), analog voltage 1-5 V
- Port size
- ø4 mm push-in
- Protection
- IP40 (IEC)
- Repeatability
- Within ±1 % F.S.
- Supply voltage
- 12 to 24 VDC ±10 %
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | PANASONIC FM-252-4-P FM-200 Digital Flow Sensor 500 mL/min PNP |
|---|---|
| Brand | PANASONIC |
| Model | FM-252-4-P |
| Category | Pressure, Flow & Temperature |
| Output | PNP open-collector (comparative outputs 1/2), analog voltage 1-5 V |
| Port size | ø4 mm push-in |
| Protection | IP40 (IEC) |
| Repeatability | Within ±1 % F.S. |
| Supply voltage | 12 to 24 VDC ±10 % |
| Applicable fluid | Clean air, compressed air, nitrogen gas |
| Ambient temperature | 0 to +50 °C |
| Full scale flow rate | 500 mL/min |
| Rated pressure range | -0.09 to +0.7 MPa |
| Instant flow display range | -550 to +550 mL/min |
