AUTONICS TMHE-82RE TMH Series Digital Input/Alarm Output Module
- Brand
- AUTONICS
- Model
- TMHE-82RE
- GEARWELL SKU
- GWP-000022057
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- Digital input 1 to 8 (contact or solid-state)
- Output
- Alarm output 1 to 8, relay 250VAC 3A 1a
- Points
- 8 points
- Evidence
- Autonics instruction manual DRW170724AD, TMH Series option modules (hosted at assets.testequity.com)
- Module type
- Digital input / alarm output option module
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TMHE-82RE TMH Series Digital Input/Alarm Output Module |
|---|---|
| Brand | AUTONICS |
| Model | TMHE-82RE |
| Category | Pressure, Flow & Temperature |
| Input | Digital input 1 to 8 (contact or solid-state) |
| Output | Alarm output 1 to 8, relay 250VAC 3A 1a |
| Points | 8 points |
| Evidence | Autonics instruction manual DRW170724AD, TMH Series option modules (hosted at assets.testequity.com) |
| Module type | Digital input / alarm output option module |
| Power supply | 24VDC |
| Communication | RS485 (Modbus RTU) master; TTL PC loader (Modbus RTU) |
| Display method | None - parameter setting and monitoring at external devices (PC, PLC, etc.) |
| Power consumption | Max. 5W (for max. load) |
| Protection structure | IP20 (IEC standard) |
