AUTONICS TR1D-T4RR TR1D Series Slim PID Temperature Controller
- Brand
- AUTONICS
- Model
- TR1D-T4RR
- GEARWELL SKU
- GWP-000022059
- Category
- Pressure, Flow & Temperature
Key specifications
- Input type (CT)
- 0.0-50.0A(primary current measurement range) ※CT ratio=1/1000
- Option output
- Alarm: AL1, AL2: 250VAC 3A 1a; Trans.: DC 4 - 20 mA (load resistance: ≤ 500 Ω, output accuracy: ±0.3% F.S.); Comm.: RS485 communication output (Modbus RTU/ASCII method)
- Power voltage
- 100-240VAC 50/60Hz
- Control method
- ON/OFF, P, PI, PD, PID
- Control output
- Relay 250VAC 3A 1a
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TR1D-T4RR TR1D Series Slim PID Temperature Controller |
|---|---|
| Brand | AUTONICS |
| Model | TR1D-T4RR |
| Category | Pressure, Flow & Temperature |
| Input type (CT) | 0.0-50.0A(primary current measurement range) ※CT ratio=1/1000 |
| Option output | Alarm: AL1, AL2: 250VAC 3A 1a; Trans.: DC 4 - 20 mA (load resistance: ≤ 500 Ω, output accuracy: ±0.3% F.S.); Comm.: RS485 communication output (Modbus RTU/ASCII method) |
| Power voltage | 100-240VAC 50/60Hz |
| Control method | ON/OFF, P, PI, PD, PID |
| Control output | Relay 250VAC 3A 1a |
| Display method | 7-segment (red) 4-digit |
| Input type (RTD) | DPt100Ω, Cu50Ω, Nickel120Ω (permissible line resistance max. 5Ω) |
| Sampling cycle | 50, 100, 250 ms |
| Power consumption | Max. 8VA |
| Input type (thermocouple) | K(CA), J(IC), L(IC), T(CC), R(PR), S(PR) |
