AUTONICS TMHA-42AE TMH Series 4-Channel Analog I/O Option Module
- Brand
- AUTONICS
- Model
- TMHA-42AE
- GEARWELL SKU
- GWP-000022054
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- Temperature sensor/analog input 1 to 4 (thermocouple, RTD, 0-100mV/0-5V/1-5V/0-10V, 0-20/4-20mA)
- Output
- Transmission output (DC 4-20mA or DC 0-20mA, load max. 500 ohm) 1 to 4
- Channels
- 4 channels
- Module type
- Analog input/output option module
- Power supply
- 24VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TMHA-42AE TMH Series 4-Channel Analog I/O Option Module |
|---|---|
| Brand | AUTONICS |
| Model | TMHA-42AE |
| Category | Pressure, Flow & Temperature |
| Input | Temperature sensor/analog input 1 to 4 (thermocouple, RTD, 0-100mV/0-5V/1-5V/0-10V, 0-20/4-20mA) |
| Output | Transmission output (DC 4-20mA or DC 0-20mA, load max. 500 ohm) 1 to 4 |
| Channels | 4 channels |
| Module type | Analog input/output option module |
| Power supply | 24VDC |
| Communication | RS485 (Modbus RTU) master; TTL PC loader (Modbus RTU) |
| Display method | None - parameter setting and monitoring at external devices (PC, PLC, etc.) |
| Sampling cycle | 50 ms |
| Power consumption | Max. 5W (for max. load) |
| Protection structure | IP20 (IEC standard) |
