AUTONICS TMHCT-82NE TMH Series 8-Point CT Input Option Module
- Brand
- AUTONICS
- Model
- TMHCT-82NE
- GEARWELL SKU
- GWP-000022056
- Category
- Pressure, Flow & Temperature
Key specifications
- Input
- CT input 1 to 8, 0.0-50.0A primary current measurement range (CT ratio 1/1000)
- Points
- 8 points
- Evidence
- Autonics instruction manual DRW170724AD, TMH Series option modules (hosted at assets.testequity.com)
- Module type
- CT input option module
- Power supply
- 24VDC
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TMHCT-82NE TMH Series 8-Point CT Input Option Module |
|---|---|
| Brand | AUTONICS |
| Model | TMHCT-82NE |
| Category | Pressure, Flow & Temperature |
| Input | CT input 1 to 8, 0.0-50.0A primary current measurement range (CT ratio 1/1000) |
| Points | 8 points |
| Evidence | Autonics instruction manual DRW170724AD, TMH Series option modules (hosted at assets.testequity.com) |
| Module type | CT input option module |
| Power supply | 24VDC |
| Communication | RS485 (Modbus RTU) master; TTL PC loader (Modbus RTU) |
| Display method | None - parameter setting and monitoring at external devices (PC, PLC, etc.) |
| Power consumption | Max. 5W (for max. load) |
| Measurement accuracy | ±5% F.S. ±1-digit |
| Protection structure | IP20 (IEC standard) |
