AUTONICS TX4M-14C TX Series LCD PID Temperature Controller

Key specifications

Alarm output: AL1: 250 VAC 3 A 1a
Power voltage: 100-240VAC 50/60Hz
Control method: ON/OFF, P, PI, PD, PID
Control output: Current DC 4-20 mA or DC 0-20 mA (parameter), Load resistance: ≤ 500 Ω; SSR 13 VDC ±3 V, ≤ 20 mA
Display method: 11 Segment (White, Green, Yellow), LCD type

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	AUTONICS TX4M-14C TX Series LCD PID Temperature Controller
Brand	AUTONICS
Model	TX4M-14C
Category	Pressure, Flow & Temperature
Alarm output	AL1: 250 VAC 3 A 1a
Power voltage	100-240VAC 50/60Hz
Control method	ON/OFF, P, PI, PD, PID
Control output	Current DC 4-20 mA or DC 0-20 mA (parameter), Load resistance: ≤ 500 Ω; SSR 13 VDC ±3 V, ≤ 20 mA
Display method	11 Segment (White, Green, Yellow), LCD type
Sampling cycle	50 ms
Input specification	Thermocouple: K(CA), J(IC), T(CC), R(PR), S(PR), L(IC); RTD: DPt100Ω, Cu50Ω
Protection structure	IP50 (Front panel, IEC standards); Insulation type; Double insulation (mark:, dielectric strength between primary circuit and secondary circuit: 3kV); Unit weight (packaged weight); ≈ 138 g (≈ 213 g)
