AUTONICS TMH4-N2RB TMH Series 4-Channel Temperature Control Module
- Brand
- AUTONICS
- Model
- TMH4-N2RB
- GEARWELL SKU
- GWP-000022036
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- TMH2/TMH4 control module
- Channels
- 4 channels
- Evidence
- Autonics instruction manual DRW170723AE, TMH Series control modules (hosted at assets.testequity.com)
- Input type
- Thermocouple, RTD (3-wire), analog 0-100mV/0-5V/1-5V/0-10V/0-20mA/4-20mA
- Module type
- Basic module (power/comm. terminal included)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | AUTONICS TMH4-N2RB TMH Series 4-Channel Temperature Control Module |
|---|---|
| Brand | AUTONICS |
| Model | TMH4-N2RB |
| Category | Pressure, Flow & Temperature |
| Series | TMH2/TMH4 control module |
| Channels | 4 channels |
| Evidence | Autonics instruction manual DRW170723AE, TMH Series control modules (hosted at assets.testequity.com) |
| Input type | Thermocouple, RTD (3-wire), analog 0-100mV/0-5V/1-5V/0-10V/0-20mA/4-20mA |
| Module type | Basic module (power/comm. terminal included) |
| Power supply | 24VDC |
| Control output | Relay output (250VAC 3A 1a) |
| Sampling cycle | 50 ms (synchronous sampling of all channels) |
| Input/output option | CT input, RS485 comm. output |
| Protection structure | IP20 |
