Allen-Bradley 1794-TBNF FLEX I/O Fused Terminal Base
- Brand
- Allen-Bradley
- Model
- 1794TBNF
- GEARWELL SKU
- GWP-000004250
- Category
- PLCs & I/O
Key specifications
- Product type
- FLEX I/O terminal base
- Maximum V/COM terminal current
- 10 A
- Lifecycle status
- Active Mature
- Termination type
- Fused NEMA-style screw clamp
- Operating temperature
- -20 to +55 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The Allen-Bradley 1794-TBNF is a fused NEMA-style screw clamp FLEX I/O terminal base with eight 5 x 20 mm fused terminals and a cover for I/O wiring, for up to 264V AC/DC. It is shipped with 1.6 A, 250V AC slow blow fuses for the 1794-OA8 and can fuse the 1794-OM8 and 1794-OW8 with replacement fuses; it is rated for -20…+55 °C (-4…+131 °F).
Technical reference
| Product name | Allen-Bradley 1794-TBNF FLEX I/O Fused Terminal Base |
|---|---|
| Brand | Allen-Bradley |
| Model | 1794TBNF |
| Category | PLCs & I/O |
| Product type | FLEX I/O terminal base |
| Maximum V/COM terminal current | 10 A |
| Lifecycle status | Active Mature |
| Termination type | Fused NEMA-style screw clamp |
| Operating temperature | -20 to +55 °C |
| Product description | Allen-Bradley 1794-TBNF is a fused FLEX I/O terminal base with NEMA-style screw-clamp connections. |
| Dimensions with I/O module installed (H × W × D) | 94 × 94 × 69 mm |
| Terminal connections | 16 I/O; 2 common; 2 +V |
