YASKAWA SGMGH-09ACA6C Sigma-II 850 W AC Servo Motor
- Brand
- YASKAWA
- Model
- SGMGH-09ACA6C
- GEARWELL SKU
- GWP-000025571
- Category
- Servo Systems
Key specifications
- Shaft (6)
- straight shaft with keyway
- Evidence
- Yaskawa Sigma II Product Catalog Supplement G-MI#99001K (hosted at rgbautomatyka.pl)
- Enclosure
- IP67 (except shaft opening), totally-enclosed self-cooled
- Encoder (C)
- 17-bit incremental encoder
- Rated output
- 0.85 kW (code 09)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA SGMGH-09ACA6C Sigma-II 850 W AC Servo Motor |
|---|---|
| Brand | YASKAWA |
| Model | SGMGH-09ACA6C |
| Category | Servo Systems |
| Shaft (6) | straight shaft with keyway |
| Evidence | Yaskawa Sigma II Product Catalog Supplement G-MI#99001K (hosted at rgbautomatyka.pl) |
| Enclosure | IP67 (except shaft opening), totally-enclosed self-cooled |
| Encoder (C) | 17-bit incremental encoder |
| Rated output | 0.85 kW (code 09) |
| Rated torque | 5.39 N m |
| Accessories (C) | 24 VDC brake |
| Rated current | 7.1 A rms |
| Rated speed (A) | 1500 rpm |
| Power supply (A) | 200 V |
| Instantaneous peak torque | 13.8 N m |
