YASKAWA SGMAH-04AAA61D-OY Sigma-II 400 W AC Servo Motor
- Brand
- YASKAWA
- Model
- SGMAH-04AAA61D-OY
- GEARWELL SKU
- GWP-000025570
- Category
- Servo Systems
Key specifications
- Evidence
- Yaskawa manual SIEP S800000 15D (hosted at mroelectric.com); Yaskawa catalog G-MI#99001K (hosted at rgbautomatyka.pl)
- Voltage (A)
- 200 V
- Connector (D)
- waterproof connector
- Shaft end (6)
- straight with key and tap
- Rated output
- 400 (code 04) W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA SGMAH-04AAA61D-OY Sigma-II 400 W AC Servo Motor |
|---|---|
| Brand | YASKAWA |
| Model | SGMAH-04AAA61D-OY |
| Category | Servo Systems |
| Evidence | Yaskawa manual SIEP S800000 15D (hosted at mroelectric.com); Yaskawa catalog G-MI#99001K (hosted at rgbautomatyka.pl) |
| Voltage (A) | 200 V |
| Connector (D) | waterproof connector |
| Shaft end (6) | straight with key and tap |
| Rated output | 400 (code 04) W |
| Code suffix "-OY" | as collected; not listed in the official model-number table |
| Rated / max. speed | 3000 / 5000 rpm |
| Serial encoder (A) | 13-bit incremental encoder (2048 P/Rev) |
| Design revision (A) | A (standard) |
| Rated / peak torque | 1.27 / 3.82 N m |
| Brake and oil seal (1) | without brake |
