YASKAWA SGDM-1AADA Sigma-II SERVOPACK 11 kW Servo Amplifier
- Brand
- YASKAWA
- Model
- SGDM-1AADA
- GEARWELL SKU
- GWP-000025569
- Category
- Servo Systems
Key specifications
- Model (D)
- for torque, speed and position control
- Evidence
- Yaskawa manual SIEP S800000 15D (hosted at mroelectric.com)
- Mounting
- base-mounted (no option suffix)
- Design revision (A)
- A
- Max. output current
- 140 A rms
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA SGDM-1AADA Sigma-II SERVOPACK 11 kW Servo Amplifier |
|---|---|
| Brand | YASKAWA |
| Model | SGDM-1AADA |
| Category | Servo Systems |
| Model (D) | for torque, speed and position control |
| Evidence | Yaskawa manual SIEP S800000 15D (hosted at mroelectric.com) |
| Mounting | base-mounted (no option suffix) |
| Design revision (A) | A |
| Max. output current | 140 A rms |
| Power supply voltage (A) | 200 V class; main circuit 200 to 230 VAC +10%/-15%, 50/60 Hz (three-phase for 11 kW) |
| Continuous output current | 58.6 A rms |
| Applicable servomotor capacity | 11.0 (code 1A) kW |
