YASKAWA JAPMC-IO2303 MP2000 LIO-04 Digital I/O Module
- Brand
- YASKAWA
- Model
- JAPMC-IO2303
- GEARWELL SKU
- GWP-000025527
- Category
- PLCs & I/O
Key specifications
- Mass
- 80 g
- Evidence
- Yaskawa America MP3300iec Hardware Manual YAI-SIA-IEC-7, ch.21 (yaskawa.de official download)
- Module name
- LIO-04
- Seller code
- JAPMC-IQ2303 (as collected; letter Q vs official letter O)
- Digital inputs
- 32 (24 VDC, 4.1 mA, sink/source)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA JAPMC-IO2303 MP2000 LIO-04 Digital I/O Module |
|---|---|
| Brand | YASKAWA |
| Model | JAPMC-IO2303 |
| Category | PLCs & I/O |
| Mass | 80 g |
| Evidence | Yaskawa America MP3300iec Hardware Manual YAI-SIA-IEC-7, ch.21 (yaskawa.de official download) |
| Module name | LIO-04 |
| Seller code | JAPMC-IQ2303 (as collected; letter Q vs official letter O) |
| Digital inputs | 32 (24 VDC, 4.1 mA, sink/source) |
| Model (official) | JAPMC-IO2303 |
| Output current | 100 mA max |
| Digital outputs | 32 (24 VDC transistor open-collector, sink mode) |
| Dimensions (H x D) | 125 x 95 mm |
| Model as collected | JAPMC-IQ2303 (Q/O typo; not an official code) |
