YASKAWA CP-9200SH/SVA CP-9200SH SVA Analog Servo Module
- Brand
- YASKAWA
- Model
- CP-9200SH/SVA
- GEARWELL SKU
- GWP-000026470
- Category
- Servo Systems
Key specifications
- Axes
- 4 per module (max. 11 SVA modules / 44 axes per CP-9200SH)
- Evidence
- YASKAWA CP-9200SH Servo Controller User's Manual SIE-C879-40.2 (yaskawa.com)
- Pulse input
- A/B/C phase, 5 V differential or 12 V pull-up collector
- Seller code
- CP-9200SH/SVA (one module; not a multi-model listing)
- Motion functions
- Position, speed, torque and phase control; analog reference
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | YASKAWA CP-9200SH/SVA CP-9200SH SVA Analog Servo Module |
|---|---|
| Brand | YASKAWA |
| Model | CP-9200SH/SVA |
| Category | Servo Systems |
| Axes | 4 per module (max. 11 SVA modules / 44 axes per CP-9200SH) |
| Evidence | YASKAWA CP-9200SH Servo Controller User's Manual SIE-C879-40.2 (yaskawa.com) |
| Pulse input | A/B/C phase, 5 V differential or 12 V pull-up collector |
| Seller code | CP-9200SH/SVA (one module; not a multi-model listing) |
| Motion functions | Position, speed, torque and phase control; analog reference |
| Counter functions | Reversible counter, interval counter, frequency measurement |
| Monitor inputs (A/D) | 8 points, speed/torque monitor 0 to ±10 V |
| Analog references (D/A) | 12 points, sign + 15 bits, full range 0 to ±11 V |
| Max. pulse counting speed | 4 Mpps (quadruple multiplication) |
