WAGO 750-597 I/O System 750 8-Channel Analog Output Module
- Brand
- WAGO
- Model
- 750-597
- GEARWELL SKU
- GWP-000010066
- Category
- PLCs & I/O
Key specifications
- Width
- 12 mm / 0.472 inches
- Isolation
- 500 V system/field
- Resolution [bit]
- 12 Bit
- Signal type (voltage)
- 0 … 10 VDC
- Supply voltage (field)
- 24 VDC (-15 … +30 %)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The WAGO 750-597 is an 8-channel analog output module of the WAGO I/O System 750 for voltage signals, listed as 0 … 10 VDC/±10 V. It resolves 12 bits with a typical conversion time of 13 ms, needs a load impedance of ≥ 2 kΩ and has an output error of 0.1 % of the upper-range value at 25 °C. Actuators connect as 8 x (2-wire) on the fixed 16-connector front, the field supply of 24 VDC (-15 … +30 %) comes via the power jumper contacts and the system-side current consumption is 61 mA. Isolation is 500 V system/field, the operating temperature is 0 … +55 °C and the size is (12 x 100 x 69) mm (W x H x D).
Technical reference
| Product name | WAGO 750-597 I/O System 750 8-Channel Analog Output Module |
|---|---|
| Brand | WAGO |
| Model | 750-597 |
| Category | PLCs & I/O |
| Width | 12 mm / 0.472 inches |
| Isolation | 500 V system/field |
| Resolution [bit] | 12 Bit |
| Signal type (voltage) | 0 … 10 VDC |
| Supply voltage (field) | 24 VDC (-15 … +30 %) |
| Supply voltage (system) | 5 VDC; via data contacts |
| Number of analog outputs | 8 |
| Ambient temperature (operation) | 0 … +55 °C |
