VICTOR 9100A Low-Voltage CT Ratio Tester

Key specifications

Evidence: VICTOR 9100A/B operating manual (maker's original document, hosted at datasheet.lcsc.com)
Function: CT ratio, phase angle, polarity and phase test (low voltage)
Data storage: approx. 3000 records
Power supply: 4 x 1.5 V AAA (No. 7) alkaline batteries
Code as collected: VICTOR 9100A

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	VICTOR 9100A Low-Voltage CT Ratio Tester
Brand	VICTOR
Model	9100A
Category	Test & Measurement
Evidence	VICTOR 9100A/B operating manual (maker's original document, hosted at datasheet.lcsc.com)
Function	CT ratio, phase angle, polarity and phase test (low voltage)
Data storage	approx. 3000 records
Power supply	4 x 1.5 V AAA (No. 7) alkaline batteries
Code as collected	VICTOR 9100A
Phase angle range	0 to 360°, ±3°
Main unit dimensions	78 x 165 x 42 mm
Ratio measuring range	1 to 500 (resolution 0.1)
Primary clamp connection	Wired
Primary current clamp range	0.0 A to 3000 A, resolution 0.1 A, ±1 %FS
Secondary current clamp range	0.00 mA to 5 A, resolution 0.01 mA, ±0.5 %FS
