Supmea PX261-B-10KLUA1M3M1WGN91000 Submersible Level Transmitter
- Brand
- Supmea
- Model
- PX261-B-10KLUA1M3M1WGN91000
- GEARWELL SKU
- GWP-000022322
- Category
- Pressure, Flow & Temperature
Key specifications
- Cable
- PVC sheath (N9), length 10 m (code 10), no probe accessory (00)
- Accuracy
- Grade 0.5 (code K)
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Probe material
- 304 SS (code M1)
- Measuring range
- 0-10 m
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea PX261-B-10KLUA1M3M1WGN91000 Submersible Level Transmitter |
|---|---|
| Brand | Supmea |
| Model | PX261-B-10KLUA1M3M1WGN91000 |
| Category | Pressure, Flow & Temperature |
| Cable | PVC sheath (N9), length 10 m (code 10), no probe accessory (00) |
| Accuracy | Grade 0.5 (code K) |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Probe material | 304 SS (code M1) |
| Measuring range | 0-10 m |
| Diaphragm material | 316L SS (code M3) |
| Process connection | M30x1.5 thread, 304SS (code LU) |
| Ordering code (decoded) | SUP-PX261-B-10-K-LU-A1-M3-M1-WG-N9-10-00 |
| Output and power supply | Two-wire 4-20 mA (code A1) |
| Electrical interface / housing | M20x1.5 cable gland, aluminium, IP65 (code WG) |
