Supmea R1000-06000000E000XX R1000 Chart Recorder
- Brand
- Supmea
- Model
- R1000-06000000E000XX
- GEARWELL SKU
- GWP-000022325
- Category
- Test & Measurement
Key specifications
- Output
- Up to 2 current outputs 4-20 mA
- Precision
- 0.2% FS
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Chart speed
- 10-1990 mm/h
- Panel cutout
- 138x138 (+1) mm
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea R1000-06000000E000XX R1000 Chart Recorder |
|---|---|
| Brand | Supmea |
| Model | R1000-06000000E000XX |
| Category | Test & Measurement |
| Output | Up to 2 current outputs 4-20 mA |
| Precision | 0.2% FS |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Chart speed | 10-1990 mm/h |
| Panel cutout | 138x138 (+1) mm |
| Power supply | 220 VAC or 24 VDC |
| Input signals | 0-5 V, 1-5 V, 0-20 mV, 0-100 mV, 0-10 mA, 4-20 mA, TC B/E/K/S/T, RTD Pt100/Cu50/Cu100 |
| Channel options | 1 / 2 / 3 / 4 / 5 / 6 / 7 / 8 (specify on order) |
| Code suffix "06000000E000XX" | as collected; not listed in an opened official model-number table (R1000 manual is a scanned PDF) |
