Supmea MP-C-CNRKSPWBXX SUP-MP-C Ultrasonic Level Transmitter
- Brand
- Supmea
- Model
- MP-C-CNRKSPWBXX
- GEARWELL SKU
- GWP-000017015
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- SUP-MP-C ultrasonic level transmitter
- Accuracy
- ±0.3 %FS / ±0.5 %FS
- Blind zone
- <=0.4 m (5 m, 10 m); <=0.6 m (15 m)
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Maker note
- Meacon (Hangzhou Meikong); series and model key published on the Supmea official site
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea MP-C-CNRKSPWBXX SUP-MP-C Ultrasonic Level Transmitter |
|---|---|
| Brand | Supmea |
| Model | MP-C-CNRKSPWBXX |
| Category | Pressure, Flow & Temperature |
| Series | SUP-MP-C ultrasonic level transmitter |
| Accuracy | ±0.3 %FS / ±0.5 %FS |
| Blind zone | <=0.4 m (5 m, 10 m); <=0.6 m (15 m) |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Maker note | Meacon (Hangzhou Meikong); series and model key published on the Supmea official site |
| Installation | Thread (standard) |
| Power supply | 18-28 VDC |
| Output options | 4-20 mA (standard), RS485, 2 relays |
| Ingress protection | Converter IP65; sensor IP68 |
| Code suffix "CNRKSPWBXX" | as collected; not listed in an official model-number table |
| Measuring range options | 5 m / 10 m / 15 m (set by order code) |
