Supmea LUGB-SUP-40GBAM1K7T5WG00 Vortex Flowmeter
- Brand
- Supmea
- Model
- LUGB-SUP-40GBAM1K7T5WG00
- GEARWELL SKU
- GWP-000022320
- Category
- Pressure, Flow & Temperature
Key specifications
- Accuracy (M)
- Class 1.5
- Brand note
- collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes
- Housing (WG)
- M20x1.5 cable gland, aluminium, IP65
- Maker note
- Meacon (Hangzhou Meikong); series and model key published on the Supmea official site
- Code suffix "00"
- as collected; not listed in the official model-number table
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Supmea LUGB-SUP-40GBAM1K7T5WG00 Vortex Flowmeter |
|---|---|
| Brand | Supmea |
| Model | LUGB-SUP-40GBAM1K7T5WG00 |
| Category | Pressure, Flow & Temperature |
| Accuracy (M) | Class 1.5 |
| Brand note | collected as 美控 meacon; brand Supmea (杭州美仪, publisher of the SUP- ordering codes); meacon's store sells the same series with MIK- codes |
| Housing (WG) | M20x1.5 cable gland, aluminium, IP65 |
| Maker note | Meacon (Hangzhou Meikong); series and model key published on the Supmea official site |
| Code suffix "00" | as collected; not listed in the official model-number table |
| Compensation (1) | Temperature and pressure compensation |
| Nominal diameter | DN40 |
| Measured medium (A) | Steam |
| Heat resistance (T5) | -40 to 260 °C |
| Code position "GB" (process connection) | as collected; not listed in the official model-number table |
| Code position "K7" (output/display/power) | as collected; not listed in the official model-number table |
