SMC AC40-06G-A AC-A Air Filter + Regulator + Lubricator Unit
- Brand
- SMC
- Model
- AC40-06G-A
- GEARWELL SKU
- GWP-000020831
- Category
- Air Preparation
Key specifications
- Body size
- 40 (3/4 port version)
- Components
- AF40-06-A + AR40-06-A + AL40-06-A
- Pressure gauge
- Round type with limit indicator (G)
- Proof pressure
- 1.5 MPa
- Set pressure range
- 0.05 to 0.7 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC40-06G-A AC-A Air Filter + Regulator + Lubricator Unit |
|---|---|
| Brand | SMC |
| Model | AC40-06G-A |
| Category | Air Preparation |
| Body size | 40 (3/4 port version) |
| Components | AF40-06-A + AR40-06-A + AL40-06-A |
| Pressure gauge | Round type with limit indicator (G) |
| Proof pressure | 1.5 MPa |
| Set pressure range | 0.05 to 0.7 MPa |
| Pipe thread / port size | Rc 3/4 (06) |
| Max. operating pressure | 1.0 MPa |
| Nominal filtration rating | 5 µm |
