SMC AC40-06-B AC-B Air Filter + Regulator + Lubricator Unit
- Brand
- SMC
- Model
- AC40-06-B
- GEARWELL SKU
- GWP-000020830
- Category
- Air Preparation
Key specifications
- Weight
- 1.53 kg
- Body size
- 40 (3/4 port version)
- Components
- AF40-06-A + AR40-06-B + AL40-06-A
- Proof pressure
- 1.5 MPa
- Set pressure range
- 0.05 to 0.85 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC40-06-B AC-B Air Filter + Regulator + Lubricator Unit |
|---|---|
| Brand | SMC |
| Model | AC40-06-B |
| Category | Air Preparation |
| Weight | 1.53 kg |
| Body size | 40 (3/4 port version) |
| Components | AF40-06-A + AR40-06-B + AL40-06-A |
| Proof pressure | 1.5 MPa |
| Set pressure range | 0.05 to 0.85 MPa |
| Pipe thread / port size | Rc 3/4 (06) |
| Recommended lubricant | Class 1 turbine oil (ISO VG32) |
| Max. operating pressure | 1.0 MPa |
| Nominal filtration rating | 5 µm |
