SMC AC40A-03D-A AC-A Filter Regulator + Lubricator Unit
- Brand
- SMC
- Model
- AC40A-03D-A
- GEARWELL SKU
- GWP-000020832
- Category
- Air Preparation
Key specifications
- Body size
- 40
- Components
- AW40-A filter regulator + AL40-A lubricator
- Set pressure range
- 0.05 to 0.7 MPa
- Float type auto drain
- N.O. (D)
- Pipe thread / port size
- Rc 3/8 (03)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC40A-03D-A AC-A Filter Regulator + Lubricator Unit |
|---|---|
| Brand | SMC |
| Model | AC40A-03D-A |
| Category | Air Preparation |
| Body size | 40 |
| Components | AW40-A filter regulator + AL40-A lubricator |
| Set pressure range | 0.05 to 0.7 MPa |
| Float type auto drain | N.O. (D) |
| Pipe thread / port size | Rc 3/8 (03) |
| Recommended lubricant | Class 1 turbine oil (ISO VG32) |
| Max. operating pressure | 1.0 MPa |
| Nominal filtration rating | 5 µm |
