SMC AC30B-03CE3-B AC-B Air Filter + Regulator Unit
- Brand
- SMC
- Model
- AC30B-03CE3-B
- GEARWELL SKU
- GWP-000020828
- Category
- Air Preparation
Key specifications
- Weight
- 0.53 kg
- Body size
- 30
- Components
- AF30-A air filter + AR30-B regulator
- Set pressure range
- 0.05 to 0.85 MPa
- Float type auto drain
- N.C. (C)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC30B-03CE3-B AC-B Air Filter + Regulator Unit |
|---|---|
| Brand | SMC |
| Model | AC30B-03CE3-B |
| Category | Air Preparation |
| Weight | 0.53 kg |
| Body size | 30 |
| Components | AF30-A air filter + AR30-B regulator |
| Set pressure range | 0.05 to 0.85 MPa |
| Float type auto drain | N.C. (C) |
| Pipe thread / port size | Rc 3/8 (03) |
| Max. operating pressure | 1.0 MPa |
| Digital pressure switch | PNP output, wiring bottom entry (E3) |
| Nominal filtration rating | 5 µm |
| Ambient and fluid temperature | -5 to 50 (with digital pressure switch) °C |
