SMC AC30B-03CG-V-A AC-A Air Filter + Regulator Unit
- Brand
- SMC
- Model
- AC30B-03CG-V-A
- GEARWELL SKU
- GWP-000020829
- Category
- Air Preparation
Key specifications
- Body size
- 30
- Attachment
- 3-port valve for residual pressure release, AF+AR+V (V)
- Components
- AF30-A air filter + AR30-A regulator
- Pressure gauge
- Round type with limit indicator (G)
- Set pressure range
- 0.05 to 0.7 MPa
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | SMC AC30B-03CG-V-A AC-A Air Filter + Regulator Unit |
|---|---|
| Brand | SMC |
| Model | AC30B-03CG-V-A |
| Category | Air Preparation |
| Body size | 30 |
| Attachment | 3-port valve for residual pressure release, AF+AR+V (V) |
| Components | AF30-A air filter + AR30-A regulator |
| Pressure gauge | Round type with limit indicator (G) |
| Set pressure range | 0.05 to 0.7 MPa |
| Float type auto drain | N.C. (C) |
| Pipe thread / port size | Rc 3/8 (03) |
| Max. operating pressure | 1.0 MPa |
| Nominal filtration rating | 5 µm |
