RKC RH900WK04VCNAZ-278M RH Series Digital Temperature Controller
- Brand
- RKC
- Model
- RH900WK04VCNAZ-278M
- GEARWELL SKU
- GWP-000022705
- Category
- Pressure, Flow & Temperature
Key specifications
- Size
- RH900: 96 x 96 mm
- Alarm
- C: upper/lower deviation alarm (common setting)
- Case color
- A: black
- Input / range
- K04: thermocouple K 0 to 800 °C
- Output 1 (heat)
- V: voltage pulse output for SSR drive
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RKC RH900WK04VCNAZ-278M RH Series Digital Temperature Controller |
|---|---|
| Brand | RKC |
| Model | RH900WK04VCNAZ-278M |
| Category | Pressure, Flow & Temperature |
| Size | RH900: 96 x 96 mm |
| Alarm | C: upper/lower deviation alarm (common setting) |
| Case color | A: black |
| Input / range | K04: thermocouple K 0 to 800 °C |
| Output 1 (heat) | V: voltage pulse output for SSR drive |
| Output 2 (cool) | Z-278M: relay contact output |
| Control action | W: AT heat/cool PID (extruder water cooling) |
| Official code format | RH900 W K04-V*C N-A/Z-278M style; collected without separators |
| Waterproof/dustproof | N: none |
