Endress+Hauser 8P3B15-15Q3/0-AAIBAJD0ADBCFHWAA1+EBJAJELW Flowmeter
- Brand
- Endress+Hauser
- Model
- 8P3B15-15Q3/0-AAIBAJD0ADBCFHWAA1+EBJAJELW
- GEARWELL SKU
- GWP-000023627
- Category
- Pressure, Flow & Temperature
Key specifications
- Measuring range
- 0 to 70,000 kg/h
- Order code root
- 8P3B = Proline Promass P 300
- Medium temperature
- -50 to +150 (option up to +205) °C
- Max. process pressure
- PN 40 / Class 150 / 20K
- Power supply options
- DC 24 V / AC 100-230 V / AC 100-230 V + DC 24 V
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Endress+Hauser 8P3B15-15Q3/0-AAIBAJD0ADBCFHWAA1+EBJAJELW Flowmeter |
|---|---|
| Brand | Endress+Hauser |
| Model | 8P3B15-15Q3/0-AAIBAJD0ADBCFHWAA1+EBJAJELW |
| Category | Pressure, Flow & Temperature |
| Measuring range | 0 to 70,000 kg/h |
| Order code root | 8P3B = Proline Promass P 300 |
| Medium temperature | -50 to +150 (option up to +205) °C |
| Max. process pressure | PN 40 / Class 150 / 20K |
| Power supply options | DC 24 V / AC 100-230 V / AC 100-230 V + DC 24 V |
| Density accuracy (liquid) | ±0.0005 g/cm³ |
| Nominal diameter range (series) | DN 8 to 50; code position "15" as collected |
| Max. measured error (liquid mass flow) | ±0.1 % |
| Code suffix "-15Q3/0-AAIBAJD0ADBCFHWAA1+EBJAJELW" | as collected; not decoded against the official Promass 300 order structure |
