RKC PF900-V8N-4*4ND/1-FK09/Y Program Controller
- Brand
- RKC
- Model
- PF900-V8N-4*4ND/1-FK09/Y
- GEARWELL SKU
- GWP-000023124
- Category
- Pressure, Flow & Temperature
Key specifications
- CT / FBR input
- N: None
- Power supply
- 4: 100 to 240 V AC
- Output 1 (OUT1)
- V: Voltage pulse output 0/12 V DC
- Output 2 (OUT2)
- 8: DC 4 to 20 mA
- Output 3 (OUT3)
- N: Not supplied
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | RKC PF900-V8N-4*4ND/1-FK09/Y Program Controller |
|---|---|
| Brand | RKC |
| Model | PF900-V8N-4*4ND/1-FK09/Y |
| Category | Pressure, Flow & Temperature |
| CT / FBR input | N: None |
| Power supply | 4: 100 to 240 V AC |
| Output 1 (OUT1) | V: Voltage pulse output 0/12 V DC |
| Output 2 (OUT2) | 8: DC 4 to 20 mA |
| Output 3 (OUT3) | N: Not supplied |
| Digital output | 4: DO 4 points, relay DO1 to DO4 |
| Code as collected | PF900 V8N-4*4ND1-FK09/Y (slash before the initial-setting position normalized to the official form) |
| Quick start code 1 | F: PID control with AT (reverse action); input K09: K thermocouple 0.0 to 400.0 °C |
| Communication / digital input | D: Digital input 6 points, DI1 to DI6 |
