OMRON GRT1-TS2T Temperature Input Module
- Brand
- OMRON
- Model
- GRT1-TS2T
- GEARWELL SKU
- GWP-000003332
- Category
- Industrial Automation Parts
Key specifications
- Applicable standards
- UC, CE, L
- Sensor type
- Thermocouple
- Product type
- SmartSlice temperature input unit
- Temperature inputs
- 2
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The OMRON GRT1-TS2T is a SmartSlice I/O Unit with 2 thermocouple inputs for types B, E, J, K, N, R, S, T, U, W and PL2 (the specifications also list L), with a cold junction sensor on the terminal block. Accuracy is ±2°C ±1 digit max., and conversion takes 250 ms for 2 points. The unit uses screwless push-in connection and measures 84x15x74 mm.
Technical reference
| Product name | OMRON GRT1-TS2T Temperature Input Module |
|---|---|
| Brand | OMRON |
| Model | GRT1-TS2T |
| Category | Industrial Automation Parts |
| Applicable standards | UC, CE, L |
| Sensor type | Thermocouple |
| Product type | SmartSlice temperature input unit |
| Temperature inputs | 2 |
