IFM KI5209 KI-3015-FPKG/NI/0,10M/PH/US100 Capacitive Sensor

Product overview

The ifm KI5209 (KI-3015-FPKG/NI/0,10M/PH/US100) is a capacitive proximity sensor in an M30 x 1.5 threaded housing 81 mm long, for non-flush mounting. Its rated sensing range is 3…15 mm, adjustable, with a factory setting of 15 mm. The real sensing range is 15 mm ± 10% and the operating distance is 0…12.1 mm. ifm gives correction factors of 0.4 for glass, 1 for water, 0.2 for ceramics and 0.2 for PVC. The PNP switching output is selectable as normally open or normally closed, rated at 250 mA and up to 40 Hz on 10…36 V DC, with reverse polarity protection. The sensor has a PBT housing, connects through a 0.1 m PUR cable ending in an M12 connector (A-coded, 4 contacts) and is rated IP65 for -25…80 °C ambient. Supplied with two lock nuts and one screwdriver.
