IFM IT5040 Inductive Sensor
- Brand
- IFM
- Model
- IT5040
- GEARWELL SKU
- GWP-000000610
- Category
- Industrial Automation Parts
Key specifications
- Protection
- IP 65; (with ifm socket duly screwed on: IP 67)
- Product type
- Inductive sensor
- Sensing range
- 2 mm
- Output function
- normally open
- Electrical design
- PNP
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm IT5040 (ITB3002BBPKG/V4A/AS) is an inductive proximity sensor in a smooth tubular Ø 6.5 mm housing 30 mm long, for flush mounting. Its rated sensing range is 2 mm. The real sensing range is 2 mm ± 10% and the operating distance on steel is 0…1.62 mm. The PNP switching output is normally open, rated at 100 mA and up to 800 Hz on 10…30 V DC, with reverse polarity and short-circuit protection. On other metals the distance is reduced by ifm's correction factors: 0.7 for stainless steel, 0.4 for brass, 0.4 for aluminum and 0.3 for copper. The sensor has a stainless steel (1.4404 / 316L) housing with an orange PBT sensing face, connects through an M8 connector (A-coded, 3 contacts) and is rated IP65 for -25…70 °C ambient. ifm lists it for use where space is restricted and it has UL approval under file E174191. Supplied with one mounting clamp.
Technical reference
| Product name | IFM IT5040 Inductive Sensor |
|---|---|
| Brand | IFM |
| Model | IT5040 |
| Category | Industrial Automation Parts |
| Protection | IP 65; (with ifm socket duly screwed on: IP 67) |
| Product type | Inductive sensor |
| Sensing range | 2 mm |
| Output function | normally open |
| Electrical design | PNP |
| Operating voltage | 10...30 V DC |
| Ambient temperature | -25...70 °C |
| Current consumption | 10 mA |
