IFM AC3200 SmartL25 4DI 4DO T C AS-Interface Control Cabinet Module
- Brand
- IFM
- Model
- AC3200
- GEARWELL SKU
- GWP-000008611
- Category
- PLCs & I/O
Key specifications
- Housing
- rectangular
- Dimensions
- 129.3 x 25.4 x 59.3 mm
- Protection
- IP 20
- Operating voltage
- 18...31.6 DC V
- Ambient temperature
- -25...60 °C
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsProduct overview
The ifm AC3200 (SmartL25 4DI 4DO T C) is an AS-Interface control cabinet module. It has four digital inputs and four digital outputs, with PNP inputs (type 2 to IEC 61131-2) powered from AS-i. The PNP outputs carry up to 1000 mA each and 4 A in total, with an output supply of 20…30 V DC. On the AS-i side it supports AS-i version 3.0 with slave profile S-7.A.7 and extended (A/B) addressing, and it needs an AS-i master with profile M4. It runs on 18…31.6 V DC from the AS-i line, drawing up to 250 mA, with an AUX supply of 20…30 V DC. The housing measures 129.3 x 25.4 x 59.3 mm and is made of PC-GF20. It mounts on a TH35 DIN rail and is rated IP20 for -25…60 °C ambient. Supplied with cage clamps.
Technical reference
| Product name | IFM AC3200 SmartL25 4DI 4DO T C AS-Interface Control Cabinet Module |
|---|---|
| Brand | IFM |
| Model | AC3200 |
| Category | PLCs & I/O |
| Housing | rectangular |
| Dimensions | 129.3 x 25.4 x 59.3 mm |
| Protection | IP 20 |
| Operating voltage | 18...31.6 DC V |
| Ambient temperature | -25...60 °C |
| Number of digital inputs | 4 |
| Number of digital outputs | 4 |
| Max. current consumption from AS-i | 250 mA |
