HIRSCHMANN RS20-1600T1T1SDAUHH RS20 Rail Switch 16-Port
- Brand
- HIRSCHMANN
- Model
- RS20-1600T1T1SDAUHH
- GEARWELL SKU
- GWP-000013278
- Category
- Industrial Communication
Key specifications
- Product code
- RS20 - Rail Switch, Fast Ethernet
- Approvals (code A)
- US Class 1 Div. 2, cUL 508
- Power supply (code D)
- 12-48 V DC and 24 V AC
- Software version code "U"
- as collected; not listed in the official configurator (listed: E = Layer 2 Enhanced, P = Layer 2 Professional)
- Software release options
- 09.1. (SW release 9.1) / XX.X. (latest SW release) (specify on order)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | HIRSCHMANN RS20-1600T1T1SDAUHH RS20 Rail Switch 16-Port |
|---|---|
| Brand | HIRSCHMANN |
| Model | RS20-1600T1T1SDAUHH |
| Category | Industrial Communication |
| Product code | RS20 - Rail Switch, Fast Ethernet |
| Approvals (code A) | US Class 1 Div. 2, cUL 508 |
| Power supply (code D) | 12-48 V DC and 24 V AC |
| Software version code "U" | as collected; not listed in the official configurator (listed: E = Layer 2 Enhanced, P = Layer 2 Professional) |
| Software release options | 09.1. (SW release 9.1) / XX.X. (latest SW release) (specify on order) |
| Temperature range (code S) | 0 to +60 °C |
| Fast Ethernet ports (code 16) | 16 x 10/100 Mbit/s |
| Uplink 1 / uplink 2 (codes T1, T1) | 1 x RJ45 / 1 x RJ45 |
| Configuration / OEM type (codes H, H) | Standard / Standard |
