Gems FS-200E PN:020-0729 FS-200E Series Shuttle Flow Switch
- Brand
- Gems
- Model
- FS-200E PN:020-0729
- GEARWELL SKU
- GWP-000021757
- Category
- Pressure, Flow & Temperature
Key specifications
- Max. flow
- 85 l/min
- Mounting
- G1"
- Part number
- 020-0729 (as collected; not in an opened listing)
- Repeatability
- ±1%
- Housing material
- Bronze
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems FS-200E PN:020-0729 FS-200E Series Shuttle Flow Switch |
|---|---|
| Brand | Gems |
| Model | FS-200E PN:020-0729 |
| Category | Pressure, Flow & Temperature |
| Max. flow | 85 l/min |
| Mounting | G1" |
| Part number | 020-0729 (as collected; not in an opened listing) |
| Repeatability | ±1% |
| Housing material | Bronze |
| Type designation | FS-200E |
| Set point options | 2.0 / 4.0 / 7.5 / 11.5 / 15.0 / 19.0 / 22.5 / 30.0 l/min (specify on order) |
| Switching function | SPDT, 20 VA, 0.5 A, 250 V~ |
| Max. operating pressure | 27 bar |
