Gems FS-550 PN56729 FS-550 Series Paddle Flow Switch
- Brand
- Gems
- Model
- FS-550 PN56729
- GEARWELL SKU
- GWP-000021758
- Category
- Pressure, Flow & Temperature
Key specifications
- Switch
- SPDT, 20 VA (N.O. or N.C.)
- Part number
- 56729
- Paddle length
- Long (1-1/2" to 3" pipe)
- Housing material
- 316 stainless steel
- Type designation
- FS-550
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems FS-550 PN56729 FS-550 Series Paddle Flow Switch |
|---|---|
| Brand | Gems |
| Model | FS-550 PN56729 |
| Category | Pressure, Flow & Temperature |
| Switch | SPDT, 20 VA (N.O. or N.C.) |
| Part number | 56729 |
| Paddle length | Long (1-1/2" to 3" pipe) |
| Housing material | 316 stainless steel |
| Type designation | FS-550 |
| Set point accuracy | ±25% |
| Electrical connection | 3-pin J-box |
| Operating temperature | -34.4 to +148.9 °C |
| Max. operating pressure | 2000 psig (138 bar) |
