Gems B3113-S67 B Series 3-Way N.C. Solenoid Valve
- Brand
- Gems
- Model
- B3113-S67
- GEARWELL SKU
- GWP-000021473
- Category
- Valves & Manifolds
Key specifications
- MOPD
- 8.6 bar (125 psig)
- CV (body / stop)
- 0.065 / 0.070
- Primary prefix
- B3113 - 3-way N.C. line connection, grommet housing
- Code suffix "S67"
- as collected; not listed in the official model-number table
- Orifice (body / stop)
- 1.59 mm (1/16 in) / 1.59 mm (1/16 in)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems B3113-S67 B Series 3-Way N.C. Solenoid Valve |
|---|---|
| Brand | Gems |
| Model | B3113-S67 |
| Category | Valves & Manifolds |
| MOPD | 8.6 bar (125 psig) |
| CV (body / stop) | 0.065 / 0.070 |
| Primary prefix | B3113 - 3-way N.C. line connection, grommet housing |
| Code suffix "S67" | as collected; not listed in the official model-number table |
| Orifice (body / stop) | 1.59 mm (1/16 in) / 1.59 mm (1/16 in) |
| Body material (standard) | 303 stainless steel |
