Gems ELS-1150 PN220465 ELS-1150 Series Electro-Optic Level Switch
- Brand
- Gems
- Model
- ELS-1150 PN220465
- GEARWELL SKU
- GWP-000021755
- Category
- Pressure, Flow & Temperature
Key specifications
- Prism
- Fused glass
- Output
- Open collector, 18 mA sink max.
- Part number
- 220465 (as collected; not in an opened listing)
- Repeatability
- ±1 mm
- Mounting options
- 1/2" NPT / 3/4"-16 straight thread (specify on order)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems ELS-1150 PN220465 ELS-1150 Series Electro-Optic Level Switch |
|---|---|
| Brand | Gems |
| Model | ELS-1150 PN220465 |
| Category | Pressure, Flow & Temperature |
| Prism | Fused glass |
| Output | Open collector, 18 mA sink max. |
| Part number | 220465 (as collected; not in an opened listing) |
| Repeatability | ±1 mm |
| Mounting options | 1/2" NPT / 3/4"-16 straight thread (specify on order) |
| Type designation | ELS-1150 |
| Operating pressure | 0 to 2500 psi |
| Operating temperature | -40 to +100 °C |
| Housing material options | Nickel-plated carbon steel / stainless steel (specify on order) |
