Gems B2017-1M-E-EO-LB-C204 B Series 2-Way N.C. Solenoid Valve
- Brand
- Gems
- Model
- B2017-1M-E-EO-LB-C204
- GEARWELL SKU
- GWP-000021471
- Category
- Valves & Manifolds
Key specifications
- MOPD
- 3.4 bar (50 psig)
- CV / KV
- 0.430 / 0.372
- O-ring
- EO - EPR
- Orifice
- 4.76 mm (3/16 in)
- Body port
- LB - 1/4-18 NPT female thread
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems B2017-1M-E-EO-LB-C204 B Series 2-Way N.C. Solenoid Valve |
|---|---|
| Brand | Gems |
| Model | B2017-1M-E-EO-LB-C204 |
| Category | Valves & Manifolds |
| MOPD | 3.4 bar (50 psig) |
| CV / KV | 0.430 / 0.372 |
| O-ring | EO - EPR |
| Orifice | 4.76 mm (3/16 in) |
| Body port | LB - 1/4-18 NPT female thread |
| Plunger seal | E - EPR |
| Code suffix "1M" | as collected; not listed in the official model-number table |
| Primary prefix | B2017 - 2-way N.C., grommet housing |
| Code suffix "C204" | as collected; not listed in the official model-number table |
| Body material (standard) | 303 stainless steel |
