Gems 4000LGA6000C2UK 4000 Series Sputtered Film Pressure Transducer
- Brand
- Gems
- Model
- 4000LGA6000C2UK
- GEARWELL SKU
- GWP-000021470
- Category
- Pressure, Flow & Temperature
Key specifications
- Series
- 4000 (bar units)
- Approvals
- CE
- Cable length
- U - no cable
- Pressure port
- G 1/4 internal (17-4 PH ss)
- Pressure datum
- Gauge
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | Gems 4000LGA6000C2UK 4000 Series Sputtered Film Pressure Transducer |
|---|---|
| Brand | Gems |
| Model | 4000LGA6000C2UK |
| Category | Pressure, Flow & Temperature |
| Series | 4000 (bar units) |
| Approvals | CE |
| Cable length | U - no cable |
| Pressure port | G 1/4 internal (17-4 PH ss) |
| Pressure datum | Gauge |
| Pressure range | 0-6 bar |
| Performance code | K - 0.1% / 0.6% |
| Code position 2 "L" | as collected; not listed in the official model-number table (datasheet lists K = 3500 ohm bridge) |
| Electrical connection | C - fixed plug size 10-6 |
