GE IC694ALG392 PACSystems RX3i 8-Channel Analog Output Module
- Brand
- GE
- Model
- IC694ALG392
- GEARWELL SKU
- GWP-000025763
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE GFK-2314V PACSystems RX3i System Manual, section 10.3 (hosted at download.astor.com.pl)
- Isolation
- 250 VAC continuous, 1500 VDC for 1 minute (field to backplane)
- Resolution
- 0.5 µA (4-20 mA), 0.625 µA (0-20 mA), 0.3125 mV (voltage) per count
- Update rate
- 8 ms approximate, all eight channels
- Output ranges
- 0 to 10 V, -10 to +10 V, 0 to 20 mA, 4 to 20 mA
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694ALG392 PACSystems RX3i 8-Channel Analog Output Module |
|---|---|
| Brand | GE |
| Model | IC694ALG392 |
| Category | PLCs & I/O |
| Evidence | GE GFK-2314V PACSystems RX3i System Manual, section 10.3 (hosted at download.astor.com.pl) |
| Isolation | 250 VAC continuous, 1500 VDC for 1 minute (field to backplane) |
| Resolution | 0.5 µA (4-20 mA), 0.625 µA (0-20 mA), 0.3125 mV (voltage) per count |
| Update rate | 8 ms approximate, all eight channels |
| Output ranges | 0 to 10 V, -10 to +10 V, 0 to 20 mA, 4 to 20 mA |
| Catalog number | IC694ALG392 |
| External supply | +24 VDC nominal (20 to 30 VDC) |
| Output channels | 1 to 8 selectable, single-ended |
| Power consumption | 110 mA from +5 VDC backplane, 315 mA from +24 VDC user supply |
