GE IC693PWR322E Series 90-30 24/48 VDC Power Supply
- Brand
- GE
- Model
- IC693PWR322E
- GEARWELL SKU
- GWP-000025760
- Category
- Power Supplies
Key specifications
- Evidence
- GE Fanuc GFK-0356P Series 90-30 PLC Installation and Hardware Manual, chapter 4 Power Supplies (hosted at qualitrol.com)
- Holdup time
- 14 ms minimum
- Input power
- 50 W maximum at full load
- 5 VDC output
- 5.0 to 5.2 VDC, 4 A overcurrent limit
- Output power
- 30 W total: +5 VDC 15 W, +24 VDC relay 15 W, +24 VDC isolated 20 W
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693PWR322E Series 90-30 24/48 VDC Power Supply |
|---|---|
| Brand | GE |
| Model | IC693PWR322E |
| Category | Power Supplies |
| Evidence | GE Fanuc GFK-0356P Series 90-30 PLC Installation and Hardware Manual, chapter 4 Power Supplies (hosted at qualitrol.com) |
| Holdup time | 14 ms minimum |
| Input power | 50 W maximum at full load |
| 5 VDC output | 5.0 to 5.2 VDC, 4 A overcurrent limit |
| Output power | 30 W total: +5 VDC 15 W, +24 VDC relay 15 W, +24 VDC isolated 20 W |
| Input voltage | 24 or 48 VDC (start 21 to 56 VDC, run 18 to 56 VDC) |
| Catalog number | IC693PWR322 |
| Revision suffix | E (as collected; hardware/firmware revision, not part of the catalog number) |
