GE IC694APU300 PACSystems RX3i High-Speed Counter Module
- Brand
- GE
- Model
- IC694APU300
- GEARWELL SKU
- GWP-000025800
- Category
- PLCs & I/O
Key specifications
- Inputs
- 12 positive logic (source), selectable 5 Vdc or 10 to 30 Vdc threshold
- Outputs
- 4 positive logic (source)
- CPU data
- 16 bits %I, 15 words %AI, 16 bits %Q
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 8.1
- Counter types
- A (4 simple), B (2 complex), C (1 complex), Z (2 with Clock Z, enhanced only)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694APU300 PACSystems RX3i High-Speed Counter Module |
|---|---|
| Brand | GE |
| Model | IC694APU300 |
| Category | PLCs & I/O |
| Inputs | 12 positive logic (source), selectable 5 Vdc or 10 to 30 Vdc threshold |
| Outputs | 4 positive logic (source) |
| CPU data | 16 bits %I, 15 words %AI, 16 bits %Q |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual (hosted at download.astor.com.pl), section 8.1 |
| Counter types | A (4 simple), B (2 complex), C (1 complex), Z (2 with Clock Z, enhanced only) |
| Hot insertion | supported on revision CA and later |
| Catalog number | IC694APU300 |
| Maximum count frequency | 1 MHz (enhanced version -CA and later), 80 kHz (classic version -BA and earlier) |
