GE IC693PWR321 Series 90-30 Standard AC/DC Power Supply
- Brand
- GE
- Model
- IC693PWR321
- GEARWELL SKU
- GWP-000025759
- Category
- Power Supplies
Key specifications
- Evidence
- GE Fanuc GFK-0356P Series 90-30 PLC Installation and Hardware Manual, chapter 4 Power Supplies (hosted at qualitrol.com)
- Holdup time
- 20 ms minimum
- Input power
- 90 VA AC / 50 W DC at full load
- Serial port
- RS-485 port on power supply
- 5 VDC output
- 5.0 to 5.2 VDC, 4 A overcurrent limit
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693PWR321 Series 90-30 Standard AC/DC Power Supply |
|---|---|
| Brand | GE |
| Model | IC693PWR321 |
| Category | Power Supplies |
| Evidence | GE Fanuc GFK-0356P Series 90-30 PLC Installation and Hardware Manual, chapter 4 Power Supplies (hosted at qualitrol.com) |
| Holdup time | 20 ms minimum |
| Input power | 90 VA AC / 50 W DC at full load |
| Serial port | RS-485 port on power supply |
| 5 VDC output | 5.0 to 5.2 VDC, 4 A overcurrent limit |
| Output power | 30 W total: +5 VDC 15 W, +24 VDC relay 15 W, +24 VDC isolated 20 W |
| Input voltage | 120/240 VAC or 125 VDC (85 to 264 VAC / 100 to 300 VDC) |
| Catalog number | IC693PWR321 |
