GE IC694CHS392 PACSystems RX3i 10-Slot Serial Expansion Backplane
- Brand
- GE
- Model
- IC694CHS392
- GEARWELL SKU
- GWP-000026596
- Category
- PLCs & I/O
Key specifications
- Evidence
- GE/Emerson GFK-2314V PACSystems RX3i System Manual, section 3.2 (hosted at download.astor.com.pl)
- I/O slots
- 10
- Rack number
- set by Rack Number Selection DIP switch
- Power supply
- leftmost slot: IC694PWR321, IC694PWR330 or IC694PWR331 serial expansion power supply
- Hot insertion
- not permitted on expansion backplanes
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC694CHS392 PACSystems RX3i 10-Slot Serial Expansion Backplane |
|---|---|
| Brand | GE |
| Model | IC694CHS392 |
| Category | PLCs & I/O |
| Evidence | GE/Emerson GFK-2314V PACSystems RX3i System Manual, section 3.2 (hosted at download.astor.com.pl) |
| I/O slots | 10 |
| Rack number | set by Rack Number Selection DIP switch |
| Power supply | leftmost slot: IC694PWR321, IC694PWR330 or IC694PWR331 serial expansion power supply |
| Hot insertion | not permitted on expansion backplanes |
| Catalog number | IC694CHS392 |
| Expansion cable length | up to 15 m (50 ft) to the Universal Backplane |
| Expansion backplanes per system | up to seven RX3i serial expansion and/or Series 90-30 expansion/remote backplanes |
