GE IC693MAR590 Series 90-30 120 VAC Input / Relay Output Module
- Brand
- GE
- Model
- IC693MAR590
- GEARWELL SKU
- GWP-000025755
- Category
- PLCs & I/O
Key specifications
- Inputs
- 8, 120 VAC (0 to 132 VAC), one group
- Outputs
- 8 normally-open relays, two groups of four
- Evidence
- GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com)
- Isolation
- 1500 V RMS field to logic
- Maximum load
- 2 A per output, 4 A per common
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693MAR590 Series 90-30 120 VAC Input / Relay Output Module |
|---|---|
| Brand | GE |
| Model | IC693MAR590 |
| Category | PLCs & I/O |
| Inputs | 8, 120 VAC (0 to 132 VAC), one group |
| Outputs | 8 normally-open relays, two groups of four |
| Evidence | GE Fanuc GFK-0898F Series 90-30 PLC I/O Module Specifications page (hosted at qualitrol.com) |
| Isolation | 1500 V RMS field to logic |
| Maximum load | 2 A per output, 4 A per common |
| Input current | 12 mA typical at rated voltage |
| Catalog number | IC693MAR590 |
| Output operating voltage | 5 to 30 VDC / 5 to 250 VAC, 50/60 Hz |
