GE IC693CPU374 Series 90-30 CPU 374 Module with Ethernet
- Brand
- GE
- Model
- IC693CPU374
- GEARWELL SKU
- GWP-000025752
- Category
- PLCs & I/O
Key specifications
- Ethernet
- 2 x 10/100BASE-T/TX ports (built-in switch, RJ-45), SRTP and EGD
- Evidence
- GE Fanuc GFK-0356Q Series 90-30 PLC Installation and Hardware Manual page (hosted at qualitrol.com)
- Processor
- Embedded 586, 133 MHz
- User memory
- 240 KB (configurable %R, %AI, %AQ)
- Discrete I/O
- 2,048 inputs %I / 2,048 outputs %Q
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693CPU374 Series 90-30 CPU 374 Module with Ethernet |
|---|---|
| Brand | GE |
| Model | IC693CPU374 |
| Category | PLCs & I/O |
| Ethernet | 2 x 10/100BASE-T/TX ports (built-in switch, RJ-45), SRTP and EGD |
| Evidence | GE Fanuc GFK-0356Q Series 90-30 PLC Installation and Hardware Manual page (hosted at qualitrol.com) |
| Processor | Embedded 586, 133 MHz |
| User memory | 240 KB (configurable %R, %AI, %AQ) |
| Discrete I/O | 2,048 inputs %I / 2,048 outputs %Q |
| Serial ports | none on CPU (RS-485 port on power supply, SNP/SNPX) |
| Catalog number | IC693CPU374 |
| Typical scan rate | 0.15 ms per 1K of logic |
| Baseplates per system | 8 |
| Operating temperature | 0 to 60 °C |
| Load from power supply | 7.4 W of 5 VDC |
