GE IC693DSM302-AE Series 90-30 Motion Mate DSM302 Servo Module
- Brand
- GE
- Model
- IC693DSM302-AE
- GEARWELL SKU
- GWP-000025754
- Category
- Servo Systems
Key specifications
- Evidence
- GE Fanuc GFK-0356Q Series 90-30 PLC Installation and Hardware Manual page (hosted at qualitrol.com)
- Servo axes
- 2 (plus auxiliary axes 3 and 4; Quad B encoder input for follower master axis)
- Description
- Motion Mate DSM302 Digital Servo Module
- Serial port
- RS-232, 6-pin RJ-11 (firmware upgrade / motion programs, cable IC693CBL316)
- Analog output
- 13-bit, PLC-controlled or servo tuning monitor
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC693DSM302-AE Series 90-30 Motion Mate DSM302 Servo Module |
|---|---|
| Brand | GE |
| Model | IC693DSM302-AE |
| Category | Servo Systems |
| Evidence | GE Fanuc GFK-0356Q Series 90-30 PLC Installation and Hardware Manual page (hosted at qualitrol.com) |
| Servo axes | 2 (plus auxiliary axes 3 and 4; Quad B encoder input for follower master axis) |
| Description | Motion Mate DSM302 Digital Servo Module |
| Serial port | RS-232, 6-pin RJ-11 (firmware upgrade / motion programs, cable IC693CBL316) |
| Analog output | 13-bit, PLC-controlled or servo tuning monitor |
| Servo control | Digital GE Fanuc servos; analog-command servos from firmware 1.40 |
| Catalog number | IC693DSM302 |
| Program storage | 10 programs and 40 subroutines (non-volatile) |
| Revision suffix | -AE (as collected; hardware/firmware revision, not part of the catalog number) |
| Block processing time | under 5 ms |
