GE IC670MDL240 Field Control 120VAC 16-Point Grouped Input Module
- Brand
- GE
- Model
- IC670MDL240
- GEARWELL SKU
- GWP-000025718
- Category
- PLCs & I/O
Key specifications
- Inputs
- 16 (one group)
- Isolation
- 250 VAC continuous, 1500 VAC for 1 minute
- Input current
- 15 mA per point @ 120 VAC
- Rated voltage
- 120 VAC
- Input voltage range
- 0-132 VAC, 47-63 Hz
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC670MDL240 Field Control 120VAC 16-Point Grouped Input Module |
|---|---|
| Brand | GE |
| Model | IC670MDL240 |
| Category | PLCs & I/O |
| Inputs | 16 (one group) |
| Isolation | 250 VAC continuous, 1500 VAC for 1 minute |
| Input current | 15 mA per point @ 120 VAC |
| Rated voltage | 120 VAC |
| Input voltage range | 0-132 VAC, 47-63 Hz |
| On / off state voltage | 70-120 VAC / 0-20 VAC |
| Response time on / off | 12 ms typ, 20 ms max / 25 ms typ, 40 ms max |
| Current from BIU power supply | 77 mA maximum |
