GE IC670MDL740J Field Control 12/24VDC 0.5A 16-Point Output Module

Key specifications

Fuse: 5 x 20 mm, 5 A 250 V slow-acting, common to all outputs
Outputs: 16, positive logic (sourcing)
Code suffix "J": as collected; GE catalog-number version suffix on base IC670MDL740 (GE documents use letter suffixes for hardware versions); not listed separately in the official model table
Output current: 0.5 A per point, 4 A per module
User supply voltage: 10-30 VDC, 24 VDC nominal

This opens your email client. Send the email to submit your inquiry; this website does not store your message.

Product name	GE IC670MDL740J Field Control 12/24VDC 0.5A 16-Point Output Module
Brand	GE
Model	IC670MDL740J
Category	PLCs & I/O
Fuse	5 x 20 mm, 5 A 250 V slow-acting, common to all outputs
Outputs	16, positive logic (sourcing)
Code suffix "J"	as collected; GE catalog-number version suffix on base IC670MDL740 (GE documents use letter suffixes for hardware versions); not listed separately in the official model table
Output current	0.5 A per point, 4 A per module
User supply voltage	10-30 VDC, 24 VDC nominal
Output voltage range	9.2-29.5 VDC
Response time on / off	200 us max with 0.5 A resistive load
Current from BIU power supply	111 mA maximum
