GE IC670MDL644 Field Control 24VDC Pos/Neg Fast Input Module
- Brand
- GE
- Model
- IC670MDL644
- GEARWELL SKU
- GWP-000034260
- Category
- PLCs & I/O
Key specifications
- Inputs
- 16, one group, positive or negative logic
- Evidence
- GE Fanuc GFK-1301B 24 VDC Positive/Negative Fast Input Module datasheet (hosted at qualitrol.com)
- Isolation
- 250 VAC continuous; 1500 VAC for 1 minute
- Input current
- 8.0 mA per point at 24 VDC
- Rated voltage
- 24 VDC (input range 0-30 VDC)
This opens your email client. Send the email to submit your inquiry; this website does not store your message.
← Back to productsTechnical reference
| Product name | GE IC670MDL644 Field Control 24VDC Pos/Neg Fast Input Module |
|---|---|
| Brand | GE |
| Model | IC670MDL644 |
| Category | PLCs & I/O |
| Inputs | 16, one group, positive or negative logic |
| Evidence | GE Fanuc GFK-1301B 24 VDC Positive/Negative Fast Input Module datasheet (hosted at qualitrol.com) |
| Isolation | 250 VAC continuous; 1500 VAC for 1 minute |
| Input current | 8.0 mA per point at 24 VDC |
| Rated voltage | 24 VDC (input range 0-30 VDC) |
| Input impedance | 3 kOhm typical |
| On response time | 25 µs typical, 60 µs max |
| Off response time | 100 µs typical, 150 µs max |
| Current from BIU supply | 80 mA |
